Welding and Cutting

DOUBLE INSULATED WELDING CABLE

Features:

Resistance to oil, solvents and chemicals
High resistance to cuts, tears & abrasion
Excellent ozone and weather resistant
Outstanding toughness
Durability

Application Area:

Rubber insulated flexible welding cable are used to connect Welding Machine & for better welding proficiency.
Used in Automobile industries, Shipbuilding, Transport, Steel Plants, Railways, Refineries, Oil fields, Automatic Welding Robots, Construction, Coal Mines etc.
The robust construction makes these cables resistance to both cold & heat as well as to flames.
They are suitable for use in open spaces and in dry and damp conditions.

Category: Welding and Cutting

Description

Cable Structure:

Plain copper conductors, extra fine stranded to IS 8130/84 equivalents to BS 6360, IEC 60228 & HD 383.
Melinex tape used as separator over the conductor.
EPR/NBR outer rubber jacket, as per type SE-3.
Outer sheathing black.
With marking of brand name and cross section.
Testing of cable carried out as per IS 9857/90 equivalents to BS 638 part 4.
Heat, oil and fire retardant cable
